ncm moscow e-bike e-mtb e-mountainbike 48v 13ah 624wh NCM Moscow M3

Specs

• Motor: Das-Kit Rear Hub Motor 500W, 60 Nm
• Battery: Das-Kit Integrated 576Wh 48V12A
• Range: 35–80 km (25–50 miles)
• Charge Time: 6 hours for a full charge (50% in ~3 hours)
• Top Speed: 32 km/h (20 mph)
• Frame: 6061 double-butted aluminum alloy
• Weight: 59 lbs (26.8 kg)
• Max Rider Weight: 275 lbs (125 kg)
• Gearing: 3×7 Shimano Tourney (11–32T)
• Chain: KMC Z51
• Brakes: Tektro MD-M280 mechanical disc
• Front Fork: Suntour XCT-26/27.5/29
• Front Light: DH007Plus 70 Lux
• Display/Controller: Das-Kit L7 Bar Mount LCD; CT6-I6 Das-Kit Controller
• Wheels/Tires: Arisun Mount Cronos, 26×2.30 / 27.5×2.35 / 29×2.35
• Saddle: VELO VL-3410
• Seat Post: Forged alloy, 27.2 mm, quick-release
• Stem: Threadless 31.8 mm
• Crank: Forged alloy, 170 mm, 3-speed
• Pedals: Wellgo alloy platform
• Kickstand: Center-mounted, adjustable length
• Charger: Das-Kit 48V2A
• Max Load (Rider + Bike): 275 lbs (125 kg)
• Certifications: TÜV UL 2849 compliance for electronics

Features

• Integrated GPS tracking for navigation and ride monitoring
• Built-in secure lock for theft protection
• Front suspension with a high-travel fork to absorb shocks on rough terrain
• Integrated 70 Lux front light for improved visibility
• Das-Kit L7 LCD display provides ride stats (speed, distance, battery)
• 6-level pedal assist (0–6) with a thumb throttle for versatile power
• Rear hub motor delivering 60 Nm torque for confident acceleration and hill climbing
• Rugged aluminum frame designed for urban commuting and off-road exploration
• Ready for both city streets and trails with compatible wheel configurations

Compatibility

• Wheel configurations: 26", 27.5", and 29" with matching tires
• Sizes: S (26"), M (27.5"), L (29") to fit a range of rider heights
• Max rider weight: 275 lbs (125 kg)
• Seat post diameter: 27.2 mm with quick-release clamp
• Frame: 6061 aluminum alloy
• Front fork: Suntour XCT series
• Gearing: 3×7 with 11–32T cassette
• Brakes: Tektro MD-M280 mechanical discs
• Charger: Included Das-Kit 48V2A
• Certification: TÜV UL 2849 compliant electronics

Physical

• Frame material: 6061 aluminum alloy
• Color/appearance: White frame with blue accent lines on the top tube and downtube
• Weight: 59 lbs (26.8 kg)
• Seat post: 27.2 mm with quick-release clamp
• Saddle: VELO VL-3410
• Stem: Threadless 31.8 mm
• Crank: Forged alloy, 170 mm, 3-speed
• Pedals: Wellgo alloy platform
• Kickstand: Center-mounted, adjustable length
• Included accessories: Kickstand
• Brand: NCM Moscow M3, designed for urban commuting and off-road adventures
